SAE Felt Specifications

SAE Grade No. Lbs. per Sq. yd, 1" Color Wool Content Tensile Strength Shore A Hardness Compression for 10% Deflection, psi Vibration Absorption Abrasion Resistance
F-1 16.0 White 95% 500 30-40 21 High Excellent
F-2 16.0 Pnk/Blk/Brwn 90% 500 30-40 21 High Excellent
F-3 16.0 Grey 85% 400 30-40 13 High Excellent
F-5 12.24 White 95% 400 20-30 6 Medium Good
F-7 12.24 Grey 80% 250 20-30 6 Medium Good
F-10 8.48 White 95% 225 15-25 4 Low Fair
F-11 8.48 Grey 87% 200 15-25 4 Low Fair
F-13 8.48 Grey 75% 75 15-25 3 Low Fair
F-15 8.48 Grey 55% 75 15-25 3 Low Fair
F-26 7.20 Grey 45% Not Rated 5-15 1 Very Low Poor

F-50 - similar to F-1 but in thickness less than 1/8"

F-51 - similar to F-3 but in thickness less than 1/8"

F-55 - similar to F-7 but in thickness less than 1/8"



SAE felt specifications
